Thermal Anemometer 405

Deskripsi

Alat untuk mengukur kecepatan udara, aliran volumetrik, dan suhu udara.

Velocity -Thermal anemometer
Measuring range	0 to 5 m/s (-20 to 0 °C) 0 to 10 m/s (0 to +50 °C) 0 to 99990 m³/h
Accuracy	±(0.1 m/s + 5 % of mv) (0 to 2 m/s) ±(0.3 m/s + 5 % of mv) (Remaining Range)
Resolution	0.01 m/s

Velocity -Thermal anemometer

Measuring range

0 to 5 m/s (-20 to 0 °C)

0 to 10 m/s (0 to +50 °C)

0 to 99990 m³/h

Accuracy

±(0.1 m/s + 5 % of mv) (0 to 2 m/s)

±(0.3 m/s + 5 % of mv) (Remaining Range)

Resolution

0.01 m/s

General technical data
Weight	115 g (with batteries, without packaging)
Dimensions	490 x 37 x 36 mm
Operating temperature	0 to +50 °C
Battery type	3 AAA micro batteries
Battery life	Approx. 20 h
Display type	LCD (Liquid Crystal Display)
Length probe shaft	300 mm
Diameter probe shaft	16 mm
Diameter probe shaft tip	12 mm
Storage temperature	-20 to +70 °C
