Spesifikasi
| Materials Resistive element | CuNi alloy foil |
|---|---|
| Materials Base | Polyimide |
| Operating temperature in combination with major adhesives after curing (°C) | CC-33A: -10 to 120ºC CC-36: -10 to 100ºC CC-35: -10 to 120ºC EP-340: -10 to 120ºC |
| Operating temperature in combination with major leadwire cables (°C) | Polyester-coated copper lead-wire cable NT: -10 to 120ºC |
| Self-temperature-compensation (°C) | 10 to 100ºC |
| Applicable linear expansion coefficients (×10-6/℃) | 11, 16, 23, 27 |
| Strain limits at normal temp. (approx. %) | 3.0% |
| Fatigue lives at normal temp. (times) | 1×106 (±1500 μm/m) |
