| Operating Range |
RX2105: -40° to 60°C (-40° to 140°F) |
| Smart Sensor Connectors |
5 |
| Smart Sensor Network Cable Length |
100 m (328 ft) maximum |
| Smart Sensor Data Channels |
Maximum of 15 (some smart sensors use more than one data channel; see sensor manual for details) |
| Logging Rate |
1 minute to 18 hours |
| Time Accuracy |
±8 seconds per month in 0° to 40°C (32°F to 104°F) range;
±30 seconds per month in -40° to 60°C (-40° to 140°F) range |
| Battery Type/Power Source |
RX2105: AC power adapter (P-AC-1) and 6 AA 1.5 V lithium batteries |
| Battery Life/Power Source |
RX2105:
Runs continuously with the included AC adapter.
Batteries can be used as a backup to AC power; battery life of 3 months with 1 minute logging and daily connections or 2 months with 1 minute logging and hourly connections, and with approximately 10 motes. Note: Deployments in areas with weak cellular strength could reduce battery life. |
| Alarm Notification Latency |
Logging interval plus 2–4 minutes, typical |
| Enclosure Access |
Hinged door secured by two latches with eyelets for use with user-supplied padlocks |
| LCD |
LCD is visible from 0° to 50°C (32° to 122°F); the LCD may react slowly or go blank in temperatures outside this range |
| Materials |
Outer enclosure: Polycarbonate/PBT blend with brass inserts; Interior: Polycarbonate/PBT; Gasket: Silicone foam; Cable channel: Santoprene™ TPE; U-Bolts (not included): Steel with zinc dichromate finish |
| Dimensions |
19.95 x 13.68 x 7.49 cm (7.85 x 5.39 x 2.95 in.); see diagrams at left |
| Weight |
678 g (23.9 oz) |
| Mounting |
Optional U-bolts are compatible with masts up to 4.14 cm (1.63 in.) mast diameter; can also be mounted with zip ties or mounted to a flat surface with screws |
| Environmental Rating |
Weatherproof enclosure, NEMA 4X and IP66 (requires proper installation of cable channel system) |
| Wireless Radio |
GSM/GPRS/EDGE: Quad band 850/900/1800/1900 MHz
UMTS/HSPA+: Seven band 800/850/900/1800/1900/2100 MHz
LTE: Twelve Band 700/800/850/900/1800/1900/2100/2600 MHz |
| Antenna |
4G LTE |
|
|
Federal Communication Commission |
|
|
European Union Compliance |
|
|
Australia and New Zealand Compliance |
|
|
Taiwan NCC Mark |
| Operating Range |
-25° to 60°C (-13° to 140°F) |
| Radio Power |
12.6 mW (+11 dBm) non-adjustable |
| Transmission Range |
Reliable connection to 457.2 m (1,500 ft) line of sight at 1.8 m (6 ft) high
Reliable connection to 609.6 m (2,000 ft) line of sight at 3 m (10 ft) high |
| Wireless Data Standard |
IEEE 802.15.4 |
| Radio Operating Frequencies |
RX210x-922: 916–924 MHz
RX210x-921: 921 MHz
RX210x-900: 904–924 MHz
RX210x-868: 866.5 MHz |
| Modulation Employed |
OQPSK (Offset Quadrature Phase Shift Keying) |
| Data Rate |
Up to 250 kbps, non-adjustable |
| Duty Cycle |
<1% |
| Maximum Number of Motes |
50 motes per one HOBOnet wireless sensor network |
| Power Source |
Powered by the station |
| Dimensions |
Mote: 16.2 x 8.59 x 4.14 cm (6.38 x 3.38 x 1.63 inches)
Cable length: 2 m (6.56 ft) |
| Weight |
159 g (5.62 oz) |
| Materials |
PCPBT, silicone rubber seal |
| Environmental Rating |
IP67, NEMA 6 |
