Thermocouple
| Type |
Range |
Accuracy |
Resolution |
| J |
-210° to 760°C (-346° to 1,400°F) |
±0.6°C (±1.08°F) ± thermocouple probe accuracy |
0.03°C (0.06°F) |
| K |
-260° to 1,370°C (-436° to 2,498°F) |
±0.7°C (±1.26°F) ± thermocouple probe accuracy |
0.04°C (0.07°F) |
| T |
-260° to 400°C (-436° to 752°F) |
±0.6°C (±1.08°F) ± thermocouple probe accuracy |
0.02°C (0.03°F) |
| E |
-260° to 950°C (-436° to 1,742°F) |
±0.6°C (±1.08°F) ± thermocouple probe accuracy |
0.03°C at (0.05°F) |
| R |
-50° to 1,550°C (-58° to 2,822°F) |
±2.2°C (±3.96°F) ± thermocouple probe accuracy |
0.08°C (0.15°F) |
| S |
-50° to 1,720°C (-58° to 3,128°F) |
±2.2°C (±3.96°F) ± thermocouple probe accuracy |
0.08°C (0.15°F) |
| B |
550° to 1,820°C (1,022° to 3,308°F) |
±2.5°C (±4.5°F) ± thermocouple probe accuracy |
0.1°C (0.18F) |
| N |
-260° to 1,300°C (-436° to 2,372°F) |
±1.0°C (±1.8°F) ± thermocouple probe accuracy |
0.06°C (0.11°F) |
Internal 10K Thermistor (Temperature):
Range: Logging: -20° to 70°C (-4° to 158°F)
Acuracy: ±0.21°C from 0° to 50°C (±0.38°F from 32° to 122°F), see Plot A
Resolution: 0.024°C at 25°C (0.04°F at 77°F); see Plot A
Drift: <0.1°C (0.18°F) per year
Logger
Logger Operating Range
Logging: -20° to 70°C (-4° to 158°F); 0 to 95% RH (non-condensing); logger accuracy from 0° to 50°C (32° to 122°F)
Launch/readout: 0° to 50°C (32° to 122°F) per USB specification
Logging rate: 1 second to 18 hours, 12 minutes, 15 seconds
Logging modes: Normal, Burst or Statistics
Memory modes: Wrap when Full or Stop when Full
Start modes: Immediately, Push Button, Date & Time or Next Interval
Stop modes: When Memory Full, Push Button, or Date & Time
Restart mode: Push Button
Time accuracy: ±1 minute per month at 25°C (77°F), see Plot B
Battery life: 1 year, typical with logging rate of 1 minute and sampling interval of 15 seconds or greater
Battery type: Two AAA 1.5V alkaline batteries, user replaceable
Memory: 4 MB (1.6 million measurements, maximum)
Download type: USB 2.0 interface
Full memory download time: Approximately 1.5 minutes
LCD: LCD is visible from: 0° to 50°C (32° to 122°F); the LCD may react slowly or go blank in temperatures outside this range
Size: 10.8 x 5.41 x 2.54 cm (4.25 x 2.13 x 1 in.)
Weight: 107.5 g (3.79 oz)
Environmental rating: IP50
– The CE Marking identifies this product as complying with all relevant directives in the European Union (EU)
