HOBO Rain Gauge Data Logger

HOBO Rain Gauge Data Logger

Jika anda berminat untuk membeli alat HOBO Rain Gauge Data Logger yang disediakan oleh Global Intan Teknindo, silahkan anda langsung hubungi kami melalui :

PT. Global Intan Teknindo

Kategori: , , , , , , , , , , , , , , , , Tag:

Deskripsi

Overview

Sistem pengumpulan dan pencatatan data curah hujan bertenaga baterai yang mencakup pencatat data HOBO Pendant Event yang diintegrasikan ke dalam penakar hujan tipping-bucket. Model ini secara otomatis mencatat curah hujan hingga 160 inci dengan kecepatan hingga 12,7 cm (5 inci) per jam. Mengumpulkan data curah hujan, waktu, dan durasi dengan mudah, serta suhu saat digunakan dengan pelindung radiasi matahari opsional (Pelindung Radiasi Matahari RS1 atau M-RSA). Diperlukan stasiun pangkalan atau pesawat ulang-alik.

Features

  • High quality tipping-bucket rain gauge includes a HOBO Pendant Event data logger. Base station or shuttle is required
  • Time and date stamp is stored for each tip – provides detail needed to determine rainfall rates and duration
  • Reliable, field-proven rain gauge
  • Compatible with HOBOware and HOBOware Pro software for logger setup, graphing, and analysis
  • Also records temperature when used with an optional solar radiation shield

Spesifikasi

Rain Gauge

Maximum Rainfall Rate
12.7 cm per hour
5 in. per hour
Calibration Accuracy
±1.0% (up to 1 in. per hour)
Resolution
0.01 in.
Calibration
Requires annual field calibration, see Field Calibration section in manual
Operating Temperature Range
0° to 50°C
32° to 122°F
Storage Temperature Range
-20° to 70°C
-4° to 158°F
Environmental Rating
Weatherproof
Housing
15.24 cm aluminum collector and base
6 in. aluminum collector and base
Tipping-bucket Mechanism
Stainless steel shaft with brass bearings
Dimensions
25.72 cm height x 15.24 cm diameter
10.125 in. height x 6 in. diameter
15.39 cm receiving orifice
6.06 in. receiving orifice
Weight
1.2 Kg
2.5 lbs

Logger

Time Stamp Resolution
1.0 second
Time Accuracy
±1 minute per month at 25°C (77°F)
Operating Range
-20° to 70°C
-4° to 158°F
Environmental Rating (for Logger Used Outside of Rain Gauge)
Tested to NEMA 6 and IP67; suitable for deployment outdoors
NIST Traceable Certification
Available for temperature only at additional charge; temperature range -20° to 70°C (-4° to 158°F)
Battery
CR-2032 3V lithium battery; 1 year typical use
Memory
64K bytes – 16K to 23K when recording events only; 25K to 30K data points when recording events and temperature; see Data Storage.
Materials
Polypropylene case; stainless steel screws; Buna-N O-ring; PVC cable insulation

Temperature Measurement (see Using the Logger for Temperature Measurement section)

Measurement Range
-20° to 70°C
-4° to 158°F
Accuracy
±0.54°C from 0° to 50°C (± 0.97°F from 32° to 122°F), see manual for plot. A solar radiation shield is required for accurate temperature measurements in sunlight.
Resolution
0.10°C at 25°C , see manual for plot
0.18°F at 77°F , see manual for plot
Drift
Less than 0.1°C/year (0.2°F/year)
Response Time
Airflow of 1 m/s (2.2 mph): 10 minutes, typical to 90%
