HOBO MX Soil Moisture and Temperature Data Logger

Jika anda berminat untuk membeli alat HOBO MX Soil Moisture and Temperature Data Logger yang disediakan oleh Global Intan Teknindo, silahkan anda langsung hubungi kami melalui :

PT. Global Intan Teknindo

Kategori: Brand:

Deskripsi

HOBO MX Soil Moisture and Temperature Data Logger merupakan data logger terintegrasi untuk pemantauan kelembapan dan suhu tanah. Perangkat ini mendukung pengukuran akurat pada berbagai aplikasi pertanian, penelitian, dan pemantauan lingkungan. Teknologi Bluetooth memudahkan pengguna melakukan konfigurasi serta mengunduh data tanpa menggunakan kabel. Pengguna cukup memakai aplikasi HOBOconnect melalui ponsel, tablet, atau komputer Windows.

Sensor TEROS 10 yang terpasang menawarkan daya tahan tinggi untuk penggunaan lapangan dalam jangka panjang. Perangkat bekerja pada tanah mineral maupun media tanam tanpa tanah. Ujung sensor berbahan baja tahan karat mempermudah pemasangan serta meningkatkan kontak dengan tanah. Desain ringkas dan tahan cuaca mendukung penggunaan pada berbagai kondisi lingkungan.

HOBO MX Soil Moisture and Temperature Data Logger tersedia dalam dua pilihan model. MX2306 mengukur kelembapan tanah, sedangkan MX2307 mengukur kelembapan dan suhu tanah. Rentang pengukuran kelembapan mencapai 0,00 hingga 0,64 m³/m³ pada tanah mineral. Media tanam tanpa tanah memiliki rentang pengukuran hingga 0,70 m³/m³. Sensor suhu pada MX2307 mengukur suhu dari -40 hingga 100 derajat Celsius.

Pengguna dapat melihat data secara langsung melalui aplikasi HOBOconnect. Sistem juga memungkinkan penyimpanan data pada layanan HOBOlink menggunakan MX Gateway opsional. Data pengukuran membantu meningkatkan efisiensi irigasi dan produktivitas tanaman. Perangkat ini juga membantu mengurangi pemborosan air serta mendukung pengelolaan lingkungan secara berkelanjutan. Teknologi nirkabel membuat proses pemantauan menjadi lebih praktis dan efisien.

Spesifikasi

Soil Moisture: Volumetric Water Content (VWC)

Measurement Range*
0.00 to 0.64 m³/m³ in mineral soils
0.00 to 0.70 m³/m³ in soilless media
Accuracy
±0.031 m³/m³ typical in mineral soils that have solution EC <8 dS/m
±0.051 m³/m³ typical in soilless media
Resolution
0.001 m³/m³
Dielectric Measurement Frequency
70 MHz

Temperature Sensor (MX2307)

Range
-40 to 100°C (-40 to 212°F), with tip and cable immersion in fresh water up to 50°C (122°F) for one year
Accuracy
±0.25°C from -40 to 0°C
±0.45 from -40 to 32°F
±0.2°C from 0 to 70°C
±0.36 from 32 to 158°F
±0.25°C from 70 to 100°C
±0.45 from 158 to 212°F
Resolution
0.04°C
0.072°F
Drift
<0.01°C per year
0.018°F per year
Response Time
3 minutes in air moving 1 m/s; 20 seconds in stirred water
4 minutes in air moving 1 m/s with RS3-B Solar Radiation Shield

Logger

Operating Range
-25° to 60°C
-13° to 140°F
Radio Power
1 mW
0 dBm
Transmission Range
Approximately 30.5 m (100 ft) line-of-sight
Wireless Data Standard
Bluetooth Low Energy (Bluetooth Smart)
Logging Rate
1 second to 18 hours
Logging Modes
Fixed interval (normal, statistics) or burst
Memory Modes
Wrap when full or stop when full
Start Modes
Immediate, push button, date & time, or next interval
Stop Modes
When memory full, push button, date & time, or after a set logging period
Time Accuracy
±1 minute per month 0° to 50°C (32° to 122°F)
Battery Type
2/3 AA 3.6 Volt lithium, user replaceable
Battery Life
2 years, typical with logging interval of 1 minute and Bluetooth Always On enabled; 5 years, typical with logging interval of 1 minute and Bluetooth Always On disabled. Faster logging intervals and statistics sampling intervals, burst logging, remaining connected with the app, excessive downloads, and paging may impact battery life.
Memory
110,000 measurements, maximum (472 kB)
Full Memory Download Time
Approximately 60 seconds; may take longer the further the device is from the logger
Dimensions
Logger housing: 10.8 x 5.08 x 2.24 cm
4.25 x 2.0 x 0.88 in.
Soil moisture sensor: 7.5 x 5.1 x 2.4 cm
2.95 x 2.02 x 0.95 inches
Soil moisture sensor needle length: 5.4 cm (2.13 inches)
Soil moisture sensor needle diameter: 0.32 cm (0.13 inches)
Temperature sensor (MX2307) diameter: 0.53 cm (0.21 in.)
Sensor cable length: 2 m (6.56 ft)
Weight
MX2306: 229 g (80 oz)
MX2307: 267 g (94 oz)
Materials
Logger: Acetal, silicone gasket, stainless steel screws
Soil Moisture Sensor: ASA plastic body with polyurethane epoxy filling and stainless steel pins
Temperature Sensor (MX2307): Stainless steel waterproof tip
Cable: PVC, UV resistant and rodent repellent (soil moisture sensor cable)
Environmental Rating
Temperature sensor and cable (MX2307): Immersion in water up to 50°C (122°F) for 1 year

Notices

*
The sensor data can be post-calibrated if necessary (e.g. the sensor is used in non-mineral soil types or higher than standard accuracy is required). Users can apply a calibration equation to the data exported from the app. The VWC range will depend on the calibration equation.

Download Katalog
